Multi Stage Booster Ejector System

Its used to create vacuum as high as 1 torr in deodorising section. It mainly comprises of 2 boosters, 2 ejectors and 2 baromatic condensers with hoggers.


Cylindrical vessel with cooling coils for gradual cooling of oil. Oil is continuously stirred with the help of a stirrer for proper formation of crystals.

Horizontal Leaf Filters

Horizontal leafs filters are used for separating the wax from the oil after the crystallisation. Horizontal leaf filter consist of a casing with filter elements which are mounted and move on rails. The movement is controlled hydraulically.

Continuous Bleacher

The oil thoroughly mixed with earth in the oil earth mixer is then transferred to the Bleacher. It is a 2 stage vessel. In the first stage, Oil is heated to 100°C and in the second stage, bleaching takes place. Veendeep supplies steam agitated bleachers without any stirrers or mechanical parts, thus making it energy efficient and maintenance free.

PP Filters

P P Filters are used for Dewaxing of rice bran oil. These are horizontal plate type filters with retractable casing. A P.P Filter provides reduced cycle time, improved cake washing and highest cake solids..

Polish Filters

These are security filters used for filtering the oil of fine particles upto 0.5 microns sized particles.

Plate Heat Exchangers

PHE’s are widely used as heaters, coolers, heat exchangers for better efficiency. It requires less space as compared to shell and tube heat exchangers

Batch Neutralizer

Batch neutralizers are ideally suited for small capacity plants. Used for degumming and neutralizing of oil in batch refineries. It is a cylindrical vessel with conical bottom fitted with stirrers. Has provision for adding water, phosphoric acid and caustic in the same vessel.

Batch Bleacher

Batch bleachers are ideally suited for small capacity plants. A cylindrical vessel with dished ends and heating coils . It is also fitted with stirrers for thorough mixing of earth with oil. As a result superior quality oil with no traces of soaps, pigments and metals is obtained.

Batch Deodorizer

Batch deodorizers are ideally suited for small capacity plants. It is can process 3.5 to 15 tons. The deodorizer is used to remove fatty acids and other volatiles from the oil.
